Easily implement complete fab communication sequences that cover multiple steps.
With SMARTUNIFIER it is not only possible to give access to simple equipment or device data and to provide „some data to MES and Cloud“.
Moreover, with SMARTUNIFIER complete communication scenarios between equipment to upper level IT systems can be easily implemented.
These can cover all steps from identification, validation, order start as well as sending results and process data from equipment to MES or Cloud. Of course it is also possible to provide any parameter data (recipes) from MES or SCADA to equipment.
You want your IT and Digitalization moving to Industry 4.0?
Industrial Grade High Performance Communication Device
The hardware and housing of the SMARTUNIFIERBOX are designed together from the ground-up to minimize size and maximize capabilities, durability and thermal performance.
The SMARTUNIFIERBOX measures only 112 mm by 84 mm.
It is one of the smallest full-featured connectivity devices on the market.
The fanless cooling hardware is based on quad-core Apollo-Lake Atom with up to 16 GB RAM. It provides performance that not long ago required a Core CPU that could not be fitted in such a small passively-cooled footprint due to higher power consumption.
SMARTUNIFIERBOX provides dual Gbit Ethernet ports (Intel I211) that can be extended to 4 ports.
The SMARTUNIFIERBOX is able to operate at the full industrial temperature range of -40°C to 85°C.
With no fans that suffer significantly lower MTBF at extreme temperatures and an embedded CPU rated for 125°C, the reliability of the SMARTUNIFIERBOX is not affected by the extreme temperatures.
The embedded grade fanless design practically eliminates aging, which allows us to provide unconditional 5-year warranty on the SMARTUNIFIERBOX hardware.
The SMARTUNIFIERBOX device is small enough to be easily and securely mounted in nearly any IoT scenario – in a cabinet, in an equipment or just mounted behind a display, on the wall or on a furniture. SMARTUNIFIERBOX supports various mounting options including VESA and DIN-rail mounting.
